本设备式采用伺服定位，PLC控制，全自动运行的，主要采用进口电机驱动，各级传动通过链条、链轮调速等。其自动化程度高，控制可靠，调整简单，智能化操作等优点，可广泛使用在饮料，啤酒，化工，食品，医药等行业，可以对各类瓶罐子进行二次包装，与自动化灌装生产线配套使用。本机采用优质不锈钢及铝材，电器，启动系统采用进口元件，此设备故障率低，维护少，可靠性高。
This equipment adopts servo positioning, PLC control, and fully automatic operation, mainly using imported motors for driving. The transmission at all levels is adjusted by and sprockets. It has the advantages of high automation, reliable control, simple adjustment, and intelligent operation, and can be widely used in beverage, beer, chemical, food and pharmaceutical industries. It can be used for secondary packaging of various bottles and cans, and can be used with automatic filling production lines. This machine uses high-quality stainless steel and materials, and the electrical and starting systems use imported components. This equipment has a low failure rate, requires little maintenance, and has high reliability.
┃产品详情
┃ Product Details
针对塑料瓶装类的产品装箱，性价比极高。
For the packaging of products in plastic bottles, the cost performance is extremely high.
生产能力： | 10-18箱/分钟 |
额定功率： | 5kw |
最大纸箱规格(mm)： | L450*W300*H230mm |
封箱胶带尺寸(mm)： | 宽度48-60mm |
装箱机外形尺寸(mm)： | 5100*900*1460mm |
开箱机外机尺寸(mm)： | 2000*1800*1460mm |
压缩空气压力： | 1500L/min0.6-0.8MPA |
整机重量： | 2000KG |
电源： | 三相五线380v50Hz 单相220V50Hz |
控制电源： | 24VDV |
Capacity： | 10-18 case/min |
Power Rating： | 5kw |
Max Carton Size： | L450*W300*H230mm |
Packing Tape Size： | 48-60mm |
Width Packing Machine Outline Size： | 5100*900*1460mm |
Opening Machine Outside Machine Size： | 2000*1800*1460mm |
Compressed Air Pressure： | 1500L/min0.6-0.8MPA |
Weight： | 2000KG |
Power Supply： | three-phase five-wire 380v50Hz |
Control Power Supply： | 24VDV |
┃包装效果展示
┃ Packaging Effect Display
┃车间实拍
┃ Workshop Shooting
┃关于我们
┃ About us
我们是一家专业从事热收缩包装机、纸箱套标机、贴标机、码垛机、输送包装机、线等食品饮料调味品日化用品的后道包装机械专业制造商。先进的设计理念，可靠的质量服务，完善的管理制度，赢得了众多客户的赞许，“努力超越，追求卓越”是我们的不懈追求，“优质产品，星级服务”是我们对客户的承诺。
We are a professional manufacturer of heat-shrinkable packaging machine, Carton Packaging Machine, labeling machine, labeling machine, palletizer, conveyor line, etc..Advanced design concept, reliable quality service, perfect management system, has won the approval of many customers, "Strive to exceed, the pursuit of excellence” is our unremitting pursuit,"Quality products, star service” is our commitment to customers.
