采用德国西门子伺服电机PLC程序自动控制，性能稳定控制精确。具有自动进料，理瓶、收缩、冷却定型流程的全自动化功能。薄膜输送采用感应开关控制，可调控送膜长度，减少损耗。输送电机采用进口变频器控制，实现无极调度。先进的螺旋风循环结构，三层隔热层处理，节约能源。加强型冷却定型通道，可使用产品迅速定型，方便储运。具有自动上底板，和彩色印刷膜定位包装等功能。
适用于矿泉水、饮料、啤酒、白酒、输液药瓶等产品的组合包装，包装后产品紧固美观。
The PLC program of Siemens servo motor in Germany is used for automatic control, and the performance is stable and accurate. It has the fully automatic functions of automatic feeding, bottle sorting, shrinking, cooling and setting. The film conveying is controlled by induction switch, which can adjust the film conveying length and reduce the loss. The conveying motor is controlled by imported frequency converter to realize stepless scheduling. Advanced spiral air circulation structure, three-layer heat insulation treatment, saving energy. Enhanced cooling shaping channel can be used to quickly shape products and facilitate storage and transportation. It has the functions of automatic bottom plate loading and color printing film positioning and packaging.
It is suitable for the combined packaging of mineral water, beverages, beer, liquor, infusion bottles and other products, and the packaged products are tight and beautiful.
┃产品详情
┃ Product Details
整机外形尺寸： | L12000*W1560*H2600mm |
整机重量： | 5500kg |
最大包装尺寸： | L600*W400*H350 |
包装速度： | 40-45包/分钟 |
输送带宽度： | 620mm |
工作电源/功率： | 三相五线380v |
工作气压： | 0.6-0.8Mpa |
整机功率： | 60-70KW |
Overall Dimensions： | L14000*W1100*H2100mm |
Weight： | 2500kg |
Maximum Packing Size： | L420*W280*H350 |
Packing Speed： | 15-20pcs/min |
Conveyor Belt Width： | 620mm |
Power supply： | three-phase five-wire 380v |
Working Air Pressure： | 0.6-0.8Mpa |
Overall Dimensions： | L14000*W1100*H2100mm |
┃包装效果展示
┃ Packaging Effect Display
┃车间实拍
┃ Workshop Shooting
