采用德国西门子伺服电机PLC程序自动控制，性能稳定控制精确，加热箱结构合理、隔热保温，温控精度高，适用于矿泉水、饮料、啤酒、白酒、输液药瓶等产品的组合包装，包装后产品紧固美观。
The PLC program of Siemens servo motor in Germany is used for automatic control, with stable performance and accurate control, reasonable heating box structure, heat insulation and high temperature control accuracy. It is suitable for combined packaging of mineral water, beverages, beer, liquor, infusion bottles and other products, and the packaged products are tight and beautiful.
┃产品详情
┃ Product Details
采用德国西门子伺服电机PLC程序自动控制，性能稳定控制精确，加热箱结构合理、隔热保温，温控精度高。气动膨胀支撑膜卷，换膜快捷迅速，换膜只需约2分钟。
薄膜张力输送，均匀平整，切膜控制精确，切口整齐机械传动部件采用经过热处理的不锈钢或中碳钢等材料，表面喷涂质量优良，整机防锈性能强。
所有的电、气控制都符合最新的国际应用标准(CE标准)。
当停电时设有人工转动输送带装置，很容易地将加热通道里面的产品移出。
The PLC program of Siemens servo motor in Germany is used for automatic control, with stable performance and accurate control, reasonable heating box structure, heat insulation and high temperature control accuracy. Pneumatic expansion supports the film roll, and the film change is quick and quick, and it only takes about 2 minutes to change the film.
Film tension conveying, even and flat, accurate film cutting control, neat cut. Mechanical transmission parts are made of heat-treated stainless steel or medium carbon steel, with excellent surface spraying quality and strong rust-proof performance of the whole machine.
All electrical and pneumatic controls are in line with the latest international application standards (CE standards).
When there is a power failure, there is a device for manually rotating the conveyor belt, which can easily remove the products in the heating channel.
主机： | L3600*1560*1700H(mm) |
输送： | L3000*1000*1400H(mm) |
炉子： | L4000*1000*2200H(mm) |
包装物最大包装尺寸： | L420*W280*H350 |
收缩膜材料： | PE |
收缩膜厚度： | 80~90um |
每分钟最高产量： | 20-30包（可连续无极调速） |
电源总负荷： | 55KW（加热箱48kw，机械部分功率为7kw） |
机器所用压缩空气压力： | 0.6-0.8Mpa |
最大耗气量： | 0.25NM3/min |
输送带最大宽度： | 600mm,高度1120~1185mm（可调整） |
电压要求： | 380/220v |
设备重量： | 4550kg |
Host： | L3600*1560*1700H(mm) |
Transport： | L3000*1000*1400H(mm) |
Furnace： | L4000*1000*2200H(mm) |
Maximum package size of package： | L420*W280*H350 |
Shrinkage film material： | PE |
Thickness of shrink film： | 80~90um |
Maximum output per minute： | 20-30packs（continuous stepless speed regulation） |
Total load of power supply： | 55KW（48kw for heating box and 7kw for mechanical part） |
Compressed air pressure used by the machine： | 0.6-0.8Mpa |
Maximum gas consumption： | 0.25NM3/min |
Maximum width of conveyor belt： | 600mm,height1120~1185mm（adjustable） |
Voltage requirements： | 380/220v |
Equipment weight： | 4550kg |
15-20包（可连续无极调速，可选择加彩膜） | |
L9500*1560*2150H(mm) | |
PE收缩膜 | |
70~100um | |
加热箱30kw/220v（升温30kw，工作保温段20kw）机械部分功率为3.7kw | |
0.4-0.7Mpa | |
0.25NM3/min | |
600mm,高度1000~1100mm（可调整） | |
电压要求： | 380/220 |
设备重量： | 3000kg |
