采用德国西门子伺服电机PLC程序自动控制，配套先进的控制元器件，装备精良、工况稳定性。
加热箱结构合理、隔热保温，温控精度高。气动膨胀支撑膜卷，换膜快捷迅速，换膜只需约2分钟。
薄膜张力输送，均匀平整，切膜控制精确，切口整齐机械传动部件采用经过热处理的不锈钢或中碳钢等材料，表面喷涂质量优良，整机防锈性能强。
所有的电、气控制都符合最新的国际应用标准(CE标准)
当停电时设有人工转动输送带装置，很容易地将加热通道里面的产品移出。
The PLC program of Siemens servo motor in Germany is used for automatic control, and advanced control components are matched, with excellent equipment and stable working conditions.
The heating box has reasonable structure, heat insulation and high temperature control accuracy. Pneumatic expansion supports the film roll, and the film change is quick and quick, and it only takes about 2 minutes to change the film.
Film tension conveying, even and flat, accurate film cutting control, neat cut. Mechanical transmission parts are made of heat-treated stainless steel or medium carbon steel, with excellent surface spraying quality and strong rust-proof performance of the whole machine.
All electrical and pneumatic controls are in line with the latest international application standard (CE standard).
When there is a power failure, there is a device for manually rotating the conveyor belt, which can easily remove the products in the heating channel.
┃产品详情
┃ Product Details
包装速度： | 15-20包（可连续无极调速，可选择加彩膜） |
设备外形尺寸（mm）： | L9500*1560*2150H(mm) |
收缩膜材料： | PE收缩膜 |
收缩膜厚度： | 70~100um |
电源总负荷： | 加热箱30kw/220v（升温30kw，工作保温段20kw）机械部分功率为3.7kw |
机器所用压缩空气压力： | 0.4-0.7Mpa |
最大耗气量： | 0.25NM3/min |
输送带最大宽度： | 600mm,高度1000~1100mm（可调整） |
电压要求： | 380/220v |
设备重量： | 3000kg |
Packaging speed： | 15-20 packs（continuous stepless speed regulation,optional color film） |
Overall dimensions of equipment（mm）： | L9500*1560*2150H(mm) |
Shrink film material： | PE shrink film |
Shrinkage film thickness： | 70~100um |
Total load of power supply： | Heating box 30kw/220v（heating 30kw，work insulation section 20kw）the power of mechanical part is 3.7kw |
Compressed air pressure used by the machine： | 0.4-0.7Mpa |
Maxium gas consumption： | 0.25NM3/min |
Maximum belt width： | 600mm,height1000~1100mm（adjustable） |
Voltage requirement： | 380/220v |
Equipment weight： | 3000kg |
┃包装效果展示
┃ Packaging Effect Display
┃车间实拍
┃ Workshop Shooting
