矿泉水、饮料、啤酒、白酒、输液药瓶等产品的组合包装，包装后产品紧固，美观。特点：采用德国西门子伺服电机PLC程序自动控制，性能稳定，控制精确。具有自动输送进料，理瓶、收缩、冷却定型流程的全自动化功能。薄膜输送采用感应开关控制，可调控送膜长度，减少损耗。输送电机采用进口变频器控制，实现无级调速。
The combined packaging of mineral water, beverage, beer, Baijiu, infusion bottles and other products is tight and beautiful after packaging. Features: Adopting German Siemens servo motor PLC program for automatic control, with stable performance and precise control. It has fully automated functions of automatic feeding, bottle sorting, shrinkage, cooling and shaping processes. The film conveying is controlled by an induction switch, which can adjust the length of the film delivery and reduce losses. The conveyor motor is controlled by an imported frequency converter to achieve stepless speed regulation.uzhou Baoli Intelligent Packaging Co., Ltd. is specialized in providing solutions for customers: food and beverage, packaged drinking water, alcohol, dairy products, condiments and other industries. Provide 2000-64000 bottles/hour packaging solutions; Main products: wrapping machine, membrane charter, packing machine, palletizer, conveying system, etc. Welcome to visit and cooperate!
┃产品详情
┃ Product Details
适用于矿泉水、饮料、啤酒、白酒、输液药瓶等产品的组合包装，包装后产品紧固，美观。
It is suitable for the combined packaging of mineral water, beverages, beer, Baijiu, infusion bottles and other products. After packaging, the products are fastened and beautiful.
采用德国西门子伺服电机PLC程序自动控制，性能稳定，控制精确。
具有自动输送进料，理瓶、收缩、冷却定型流程的全自动化功能。
Adopting Siemens servo motor PLC program for automatic control, with stable performance and precise control.It has fully automated functions of automatic feeding, bottle sorting, shrinkage, cooling and shaping processes.
薄膜输送采用感应开关控制，可调控送膜长度，减少损耗。
The film conveying is controlled by an induction switch, which can adjust the length of the film delivery and reduce losses.
输送电机采用进口变频器控制，实现无级调速。
The conveyor motor is controlled by an imported frequency converter to achieve stepless speed regulation.
先进的螺旋风循环结构，三层隔热层处理，节约能源。
Advanced spiral wind circulation structure, three-layer insulation treatment, energy-saving.
加强型冷却定型通道，可使包装产品迅速定型，方便储运，可增加自动上底板和彩色印刷膜定位包装功能。
Enhanced cooling and shaping channels can quickly shape packaged products, facilitate storage and transportation, and add automatic bottom plate and color printing film positioning packaging functions.
整机外形尺寸： | L12000*W1560*H2600mm |
整机重量： | 5500kg |
最大包装尺寸： | L420*W280*H350mm |
包装速度： | 40-45包/分钟 |
工作气压： | 0.6-0.8Mpa |
整机功率： | 60-70kw |
Overall dimensions of the machine： | L12000*W1560*H2600mm |
Whole machine weight： | 5500kg |
Maximum packaging size： | L420*W280*H350mm |
Packaging speed： | 40-45 packs/minute |
Working pressure： | 0.6-0.8Mpa |
Whole machine power： | 60-70kw |
┃包装效果展示
┃ Packaging Effect Display
┃车间实拍
┃ Workshop Shooting
